New organic fertilizer granulator
short introduction
Scope of applicationThe new organic fertilizer granulator is widely used for granulating livestock and poultry manure, agricultural waste, sludge, humic acid and other organic materials. It is suitable for use in organic fertilizer factories, farms and environmentally friendly manure resource recycling projects.
Wet Granulation with High Balling Rate
It adopts high-speed rotating stirring teeth combined with the cylinder for granulation. The materials are quickly mixed, collided, formed into granules inside the equipment, achieving good granule forming effect.
Suitable for Organic Fertilizer Material Granulation
It has strong adaptability to fermented organic materials such as livestock and poultry manure, sludge, humic acid, and decomposed straw materials, making it suitable for organic fertilizer production lines.
Good Granule Strength and Uniform Appearance
During the granulation process, the materials are fully mixed. The finished granules have relatively uniform size and good strength, which is convenient for subsequent drying, cooling, screening, and packaging.
Continuous Production and Stable Output
It can be used together with crushers, mixers, dryers, coolers, screening machines, packaging machines, and other equipment to meet continuous production needs.
Compact Structure, Easy Operation and Maintenance
The equipment runs stably, occupies a small area, and is easy to operate and maintain. It is suitable for small, medium-sized, and large-scale organic fertilizer production projects.
| Model | Installation Angle (°) | Capacity (t/h) | Total Power (kW) | Moisture of Feeding Material | Size of Feeding Material (mesh) | Dimensions (mm) |
| SHJZ-600 | 2-2.5 | 1-1.5 | 37 | 20%-40% | 50 | 4100×1600×1150 |
| SHJZ-800 | 2-2.5 | 1.5-2.5 | 55 | 20%-40% | 50 | 4250×1850×1300 |
| SHJZ-1000 | 2-2.5 | 2-4 | 75 | 20%-40% | 50 | 4700×2350×1600 |
| SHJZ-1200 | 2-2.5 | 4-6 | 90 | 20%-40% | 50 | 4900×2550×1800 |
| SHJZ-1500 | 2-2.5 | 6-8 | 110 | 20%-40% | 50 | 5500×2800×2000 |
The new organic fertilizer granulator utilizes high-speed rotating mechanical stirring force and the resulting aerodynamic force to continuously achieve mixing, granulation, spheroidization, densification and other processes of fine powder materials inside the machine, thereby achieving the purpose of granulation This granulation method results in higher ball formation rate, more aesthetically pleasing particles, and energy savings.
